Embark on a journey of precision winding with Santong Weiye's Coil Winding Machine for Multi Layer Round. As an advanced supplier and factory deeply rooted in Shenzhen's innovation landscape, we bring cutting-edge technology to the forefront. With over 15 years of expertise, our team has meticulously designed a machine that sets new standards in winding efficiency.

Santong Weiye's commitment to excellence is exemplified in our Coil Winding Machine for Multi-Layer Round. This advanced solution showcases seamless automation, precise winding capabilities, and superior quality for multi-layered round coils. As your trusted partner, we provide innovative solutions that meet the dynamic needs of industries.

Step into the future of industrial technology with Santong Weiye. Our Coil Winding Machine for Multi-Layer Round represents a paradigm shift in winding efficiency, making us the preferred choice for businesses seeking advanced, reliable, and precise winding solutions.

Five Compelling Reasons To Choose Us:

Decades of Expertise: Benefit from our technical team's extensive 20-year experience in coil, winding machine, and automation equipment. We have amassed rich industry knowledge, and our dedicated professionals are unwavering in their commitment to delivering top-notch products and services, ensuring you receive maximum value in your production processes.

Rapid Responsiveness: Enjoy a seamless one-stop service that caters to your unique needs promptly. Our sales and technical support team is available 24/7, ready to address any challenges and guarantee the smooth operation of your production line.

Top-Quality Products: Our winding machines boast high quality, superior performance, and exceptional stability, earning favor from well-known enterprises like Huawei, Dajiang, BYD, Solardedge, Tiancun, and others. Beyond meeting production requirements, our equipment enhances efficiency, providing you with higher production efficiency and product quality.

Comprehensive Customization: Experience a full spectrum of customization services tailored to your specific needs. Our engineers collaborate closely with you to create the most suitable winding machine solutions, ensuring that the equipment's performance and functionality fully align with and exceed your expectations.

Impeccable After-Sales Support: We prioritize your after-sales service experience, offering comprehensive support that includes equipment installation, commissioning, training, maintenance, and more. Our professional and technical team is committed to swiftly resolving any issues, ensuring the normal operation and optimal use of your equipment. Count on us to provide unparalleled after-sales assistance, solving problems efficiently to guarantee your equipment's seamless functionality.

Coil Winding Machine for Multi Layer Round Details

Santong Weiye was founded in 2014 in Shenzhen, Guangdong Province, China, which enjoys the title of "Capital of Innovation", in 2019, the production plant moved from Shenzhen to Tangxia, Dongguan, the company has a number of technical backbone with more than 15 years of experience in the work of wire-winding equipment and laser equipment, Shenzhen SANTONGWEIYE Technology Co. Ltd. is a manufacturer of automation equipment and coils integrating R&D, production, sales and service of coil winding machines and flat coils. Our flat coil products, vertical coil winding machines and automation equipment have good quality and advantageous price, covering part of the European and American markets. We are looking forward to be your long-term partner in China.

1. 3T-801B circular coil multi-layer winding machine is a very practical and effective equipment for making inductance and transformer coils. It can wind flat coils of various shapes and specifications.

2. 3T-801B circular coil multi-layer winding machine is easy, convenient and fast to debug, just need to replace the mold;

3. 3T-801B circular coil multi-layer winding machine is controlled by computer and driven by servo. It can produce various circular coils with 0.2-2.0 wire diameters, and realize the integrated operation of peeling and tin coating.

4. The spindle is processed by high-precision CNC lathe and vacuum precision straightening treatment is carried out, the precision is less than 0.01mm, and the production line is more stable;

5. 3T-801B circular coil multi-layer winding machine can automatically shape flat coils on the machine by multi station control of movement;

6. 3T-801B round coil multi-layer winding machine adopts windos operation interface and 10 inch LCD screen, with clear and intuitive picture, simple operation and easy learning;

7. It can save the parameters of each specification product, and it is easy and convenient to call

8. The power system is a high-precision servo motor, which is matched with the CNC control system to make the mechanical system operate more accurately and stably;

9. 3T-801B circular coil multi-layer winding machine is controlled from the design source, which is convenient for operation and commissioning personnel;

Coil Winding Machine for Multi Layer Round Parameter

Serial number	Project	Technical parameters
1	Processing wire diameter	diameter Φ 0.2 -- 2.0mm round copper wire
2	direction of winding	Clockwise versus counterclockwise
3	Maximum working stroke of the row of wires	40mm
4	The power of the spool motor, the	AC servo 750W
5	Winding spool setting range	0.1°--359.9°
6	camshaft motor power	AC servo 1500W
7	Winding spool setting range	0.1°--359.9°
8	power of the spool motor	AC servo 750W
9	Setting range for spooling	0.1°--359.9°
10	Number of coils	1-100 laps
11	Winding speed (output per hour)	350 --- 1200PCS/H will vary according to the wire specifications and turns
12	Operating power supply	AC 220V
13	Machine specification (L*W*H)	1750*980*1650mm
14	Machine weight	400kg
15	Total power	2.4KW
